TT21 - Tilt Deck Power Up & Down Triple Axle 21,000 Lb

TT21 - Tilt Deck Power Up & Down Triple Axle 21,000 Lb

**TT21 stock photo. May be shown with optional equipment.
Click trailer image for a larger view.


Part Description Weight
TT0222073   102" X 22' Triple Axle Tilt Deck w/Power
TT0224073   102" X 24' Triple Axle Tilt Deck w/Power
TT8120073   81.5" X 20' Triple Axle Tilt Deck w/Power
TT8122073   81.5" X 22 Triple Axle Tilt Deck w/Power   4673
TT8124073   81.5" X 24' Triple Axle Tilt Deck w/Power   5064




Standard Features
Wheels: 16" 8-Hole Sliver Mod EWR Class TILT DECK
Product Line Tilt Decks Product Series: TT21
Tongue & Neck: 6" Channel (8.2 lbs/ft) Frame: 6" Channel (8.2 lbs/ft)
Up Rights: 2" x 2" x 3/16" Angle Iron Crossmembers 3" Channel (3.5 lbs/ft)
Tool Box: Front Tongue Mount Flooring: Treated Wood
Fenders: Weld On Diamond Plate Top Rail: 2" x 2" x 1/8" Tubing
Lights: D.O.T. Approved Stop, Tail, Turn and Clearance LED Wire Harness: 16 Ga. 5-Way Double Insulated Harness w/7-way plug
Hydrulic Cylinder: 3" x 10 w/1.25" Shaft Hydrulic Power Units: Double Acting Power Unit
Finishing Coat: DTM Polyurethane Coating System Finish (prep): Mechanical and/or Chemical Pretreatment for Maximum Paint Adhesion
D-Rings: 3" Standard D-Rings Axles: 3-7,000 Lb Cambered Dexter Torsion UP 3 Elec Brake
Tires: 235/80 R16 LRE Suspension: Torsion Axle
Safety Chains: 26400 Lb 3/8 x 36 G#70 Jack: 1-10K Drop Leg Spring Return
GVWR: 21,000 lb GAWR: 7,000 Lb (ea axle)
Couplers: 2-5/16" Bolt On Adjustable Turtle Coupler (25,000lb)

Axle Options:
Code Axle
ET3  3 - 7,000 Lb Dexter Torsion Axles (UP)(3 Elec Brakes)
HT3  3 - 7,000 Lb Dexter Torsion Axles (UP)(3 Hyd Drum Brakes)
ETC  3 - 7000 Lb Dexter Tors Axles (UP)(3 Elec)Forward Adjusting


Color Options:
Code SAMPLE Color
CB2 Black
CG3 Grey
CW4 White
CR5 Red
CB6 Blue
CG7 Green
CY8 Yellow
CO9 Orange
Additional Options:
Tire Upgrades
A05 ST235/80 R16 LRE 10 Ply. (standard)
A06 ST235/85 R16 LRG 14 Ply.
Couplers
C09 Coupler 2-5/16" Adjustable Flat Mount Turtle (standard)
C12 Pintle Ring 3" Adjustable Plate Mount
Floors
E02 Treated Wood Floor (standard)
E03 Steel Floor DP
E05 Rough Oak Floor
E06 No Floor On Deck
Floors/Stationary Decks
K00 Full Tilt Deck (Treated Pine) (standard)
K02 2' Stationary Deck carhauler Tilt (Treated Pine)
K04 4' Stationary Deck carhauler Tilt (Treated Pine)
K00E03 Full Tilt Deck (Steel Floor)
K02E03 2' Stationary Deck carhauler Tilt (Steel Floor)
K04E03 4' Stationary Deck carhauler Tilt (Steel Floor)
K00E05 Full Tilt Deck (Rough Oak Floor)
K02E05 2' Stationary Deck carhauler Tilt (Rough Oak Floor)
K04E05 4' Stationary Deck carhauler Tilt (Rough Oak Floor)
Fenders
F05 Diamond Plate Fenders (weld-on) (standard)
F06 Diamond Plate Fenders (removable)
F09 Heavy Duty Fenders 10" (weld on)
Cross Members
I02 12" Cross-Members
Jacks
J04 Jack Spring Loaded Drop Leg 1-10K (standard)
J05 Jack Spring Loaded Drop Leg 2-10K
Lights
L03 Lighting LED (optional)
L01 Lighting Regular
D-Rings
M03 4 - D-Rings 3" Weld On (standard)
M07 6 - D-Rings 3" Weld On
M08 8 - D-Rings 3" Weld On
M52 4 - D-Rings 4" Weld On
M04 D-Rings 4" Recessed 360 Rotational Bolt On (4 each )
M05 D-Rings 4" Recessed 360 Rotational Bolt On (6 each )
M06 D-Rings 4" Recessed 360 Rotational Bolt On (8 each )
Mud Flaps
MF1 Mud Flaps
Winch
W01 Winch Plate (8" Channel)
W10 15000lb.Winch PKG(Std 8"Channel, Batt, Charger,Mounting Hdw)
Wire Harness
WC1 Standard Wiring Harness (standard)
WC2 Cold Weather Wiring Harness
Running Boards
RB1 Running Boards
Rub Rails
RR1 Rub Rail
Solar Panel Charger
SC1 Solar Panel Charger
Wireless Remote Control
RC1 Wireless Remote Double Acting Dump Control
Spare Tires
STI Spare Tire ST235/80 R16 LRE 10 Ply. 8 Hole White Spoke
STK Spare Tire ST235/85 R16 LRG 14 Ply. 8 Hole White Spoke
Stake Pockets
SP1 4 - Additional Stake Pockets
Spare Tire Mount (universal)
TM1 Spare Tire Mount
Zinc Primer
ZP1 Zinc Primer
Road Service Program
RSP Road Service Program 903-783-3933 for Info. (standard)
